32 Channel Lite Network Video Recorder (NVR)

32CH 1U 16PoE 2HDDs Lite Network Video Recorder

SKU NVR-4216-2K17

Product Detail

32 Channel Lite Network Video Recorder (NVR)
16 Built-In PoE Ports For Easy Camera Deployment
Supports Up To 12MP High-Resolution IP Cameras
Face Recognition, Perimeter Protection & SMD Plus AI
Dual SATA Storage Bays Supporting Up To 40TB
4K HDMI Output With Alarm & Audio Integration

The SL-NVR4232-16P-4KS3 is a professional-grade 32-channel Lite Network Video Recorder designed for medium to large-scale surveillance deployments. Equipped with 16 integrated PoE ports, the recorder simplifies camera installation while supporting up to 12MP IP cameras for high-resolution monitoring. Advanced Smart H.265+ compression technology reduces bandwidth and storage consumption while maintaining excellent video quality. The system supports intelligent AI functions including face detection, face recognition, perimeter protection, SMD Plus, people counting, stereo analysis, and heat map analytics through compatible cameras. Dual SATA storage bays provide support for large-capacity hard drives, while HDMI 4K output, alarm integration, audio connectivity, and Gigabit networking ensure comprehensive surveillance management for commercial, industrial, and enterprise security environments.

Product Highlights

✔
32 Channel Lite Network Video Recorder
✔
16 Built-In PoE Ports For Easy Camera Installation
✔
Supports Up To 12MP High-Resolution IP Cameras
✔
Face Recognition, Perimeter Protection & SMD Plus AI
✔
Dual SATA Bays Supporting Up To 40TB Storage
✔
4K HDMI Output With Alarm & Audio Integration

Technical Specifications

The SL-NVR4232-16P-4KS3 is a feature-rich Lite Series network video recorder that combines intelligent AI capabilities, integrated PoE connectivity, large storage capacity, 4K display output, and comprehensive alarm and audio interfaces for advanced surveillance applications.

Model
: SL-NVR4232-16P-4KS3
Category
: Lite NVR
Product Type
: 32CH 1U 16PoE 2HDDs Lite Network Video Recorder
Video Compression
: Smart H.265+ / H.265 / Smart H.264+ / H.264
Maximum Decoding Capacity
: 8 × 1080p@30fps Or 2 × 8MP@30fps (AI Disabled)
Incoming Bandwidth
: 160 Mbps
Recording Bandwidth
: 128 Mbps
Outgoing Bandwidth
: 60 Mbps
Maximum IP Camera Resolution
: Up To 12 MP
Storage
: 2 HDD Bays
Disk Interface
: 2 SATA Ports, Up To 20 TB Each
Maximum Storage Capacity
: Up To 40 TB
PoE Ports
: 16 Ports, 10/100 Mbps, IEEE 802.3af/at
AI By Recorder
: 2-Channel SMD Plus
AI By Camera
: Face Detection, Face Recognition, Perimeter Protection, SMD Plus, People Counting, Stereo Analysis & Heat Map
Video Output
: 1 HDMI (Up To 3840 × 2160), 1 VGA
Network Port
: 1 × 10/100/1000 Mbps Ethernet (RJ-45)
Audio Input
: 1-Channel RCA
Audio Output
: 1-Channel RCA
Alarm Inputs
: 4 Channels
Alarm Outputs
: 2 Channels
USB Ports
: 2 × USB 2.0 (1 Front, 1 Rear)
RS-232
: 1 Port
Power Supply
: 100–240 VAC, 50/60 Hz
Power Consumption
: NVR <10W (Without HDD), PoE Total 130W, Max 25.5W Per Port Product Dimensions : 375.0 × 327.9 × 53.0 mm Net Weight : 2.60 kg Operating Temperature : –10°C To +55°C Operating Humidity : 10%–93% RH, Non-Condensing Certifications : CE-EMC EN 55032, CE-LVD EN 62368-1
