32CH 4HDD 1.5U Network Video Recorder

SKU NVR-5432-16P-2K23

Product Detail

This enterprise-grade WizSense Network Video Recorder is designed for large-scale intelligent surveillance environments requiring advanced AI analytics, high-capacity storage, and exceptional processing performance. Featuring support for AcuPick intelligent target search across up to 32 channels, face detection and recognition, ANPR, perimeter protection, people counting, PPE detection, heat mapping, vehicle density analysis, and smart object detection, the recorder delivers comprehensive security intelligence for mission-critical applications. With support for up to 32MP IP cameras, 384 Mbps network bandwidth, four SATA storage bays, dual HDMI and dual VGA outputs, and 16 integrated PoE ports with ePoE support, the system provides a powerful and scalable solution for enterprise, industrial, transportation, and campus surveillance deployments.

Product Highlights

Enterprise WizSense NVR With 32-Channel AcuPick AI Search
Face Recognition, ANPR, PPE Detection & Smart Analytics
Dual HDMI & Dual VGA Outputs For Multi-Monitor Viewing
16 PoE Ports With ePoE Support On Ports 1–8
Four HDD Bays Supporting Up To 80TB Storage
384 Mbps Bandwidth For Large-Scale Surveillance

Technical Specifications

This advanced WizSense Network Video Recorder combines enterprise-level AI analytics, ultra-high-resolution camera support, high-bandwidth video processing, and large-capacity storage expansion to deliver a complete intelligent surveillance platform.

Operating Interface
: Web & Local GUI
AI By Recorder
: Face Detection, Face Recognition, Perimeter Protection & SMD Plus
AI By Camera
: Face Recognition, Metadata, Perimeter Protection, SMD, Stereo Analysis, Crowd Distribution, People Counting, ANPR, Vehicle Density, Heat Map, PPE, Smart Object & Sound Detection
AcuPick
: Maximum 32 Channels
Perimeter Protection
: 4 Channels, 10 IVS Rules Per Channel
Face Detection
: Recorder 2 Channels (Up To 12 Face Images/S Per Channel); Camera 16 Channels
Face Recognition
: Up To 20 Face Databases / 20,000 Face Images
SMD Plus By Recorder
: 8 Channels
SMD By Camera
: All Channels (32 Targets/S)
ANPR By Camera
: All Channels (8 Targets/S)
Access Channels
: 32 Channels
Network Bandwidth
: AI Disabled 384/384/384 Mbps; AI Enabled 200/200/200 Mbps
Maximum Resolution
: Up To 32 MP
Decoding Capability
: AI Disabled Up To 32 × 1080p@30fps; AI Enabled Up To 24 × 1080p@30fps
Video Output
: 2 HDMI, 2 VGA
Multi-Channel Playback
: Up To 16 Channels
Video Compression
: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
Audio Compression
: G.711a, G.711u, PCM, G726
Audio In/Out
: 1 RCA Input / 2 RCA Outputs
Alarm In/Out
: 16 Inputs / 6 Outputs
Disk Interface
: 4 SATA Ports, Up To 20TB Each
Maximum Storage Capacity
: Up To 80TB
eSATA
: 1 Port
RS-232 / RS-485
: 1 / 1
USB Ports
: 3 (1 Front USB 2.0, 2 Rear USB 3.0)
Network Port
: 1 × 10/100/1000 Mbps RJ-45
PoE Ports
: 16 Ports, IEEE 802.3af/at, Ports 1–8 Support ePoE
Power Supply
: 100–240 VAC, 50–60 Hz
Power Consumption
: NVR ≤13W (Without HDD), PoE Total 150W, Max 25.5W Per Port
Net / Gross Weight
: 4.82 kg / 7.09 kg
Product Dimensions
: 440.0 × 415.1 × 70.0 mm
Operating Temperature
: –10°C To +55°C
Operating Humidity
: 10%–93% RH, Non-Condensing
Certifications
: FCC Class A, CE-EMC & CE-LVD
