8+4MP 32x Smart Dual Illumination Active Deterrence X-Spans Network PTZ Camera

SKU SDT6E432-8P-MB-A-PV1-TUX

Product Detail

The SDT6E432-8P-MB-A-PV1 is a premium 8+4MP X-Spans Network PTZ Camera designed for ultra-wide panoramic surveillance and intelligent long-range tracking. Combining a 180° panoramic overview channel with a powerful 32x optical zoom detail camera, this advanced security solution delivers exceptional monitoring performance across large outdoor areas. Powered by Xinghan Large-Scale AI Models, the camera offers intelligent WizTracking, face detection, perimeter protection, and active deterrence for highly accurate human and vehicle monitoring. Equipped with Smart Dual Illumination technology featuring IR range up to 250 meters and warm light distance up to 100 meters, the camera ensures crystal-clear monitoring in complete darkness. Ideal for highways, stadiums, industrial facilities, airports, ports, and critical infrastructure surveillance applications.

Product Overview

8+4MP X-Spans PTZ Camera With 32x Optical Zoom
180° Panoramic Monitoring With AI Tracking
Smart Dual Illumination Up To 250m IR Range
Powered By Xinghan Large-Scale AI Models
Active Deterrence With Smart Warning System
Advanced WizTracking & Perimeter Protection

Technical Specifications

The SDT6E432-8P-MB-A-PV1 X-Spans PTZ Camera combines panoramic wide-angle surveillance with advanced AI-powered PTZ tracking and long-range monitoring. Featuring dual-channel imaging, 32x optical zoom, Smart Dual Illumination, and Xinghan AI technology, this camera delivers exceptional performance for large-scale outdoor security applications and intelligent perimeter protection.

Model
: SDT6E432-8P-MB-A-PV1
Product Type
: 8+4MP Smart Dual Illumination Active Deterrence X-Spans Network PTZ Camera
Overview Channel
: 180° Wide-Angle Panoramic Image
Detail Channel
: 1/2.8" 4MP STARVIS™ CMOS
Maximum Resolution
: 8MP + 4MP Dual Channel Output
Optical Zoom
: 32x Optical Zoom
Frame Rate
: Max. 25/30 fps @ 8MP & 4MP
Night Vision
: IR Distance Up To 250m
Warm Light Range
: Up To 100m
AI Platform
: Xinghan Large-Scale AI Models
AI Features
: WizTracking, Face Detection & Perimeter Protection
Active Deterrence
: Smart Warning & Active Defense System
Lighting Technology
: Smart Dual Light+
Series Category
: X-Spans Network PTZ Camera
Focal Length
: Overview 2.8 mm / Detail 5 mm–125 mm
Protection Rating
: IP66 Weatherproof
Application
: Large Area AI Surveillance & Intelligent Tracking
