8CH Penta-brid 4K Value/5MP Compact 1U 1HDD WizSense Digital Video Recorder

SKU SL-XVR-5108H-4KL-2K31

Product Detail

This advanced AI-powered 8-channel XVR is designed to deliver intelligent video surveillance for residential, commercial, retail, and small business security applications. Built on an industrial-grade processor and embedded Linux platform, the recorder supports HDCVI, AHD, TVI, CVBS, and IP camera technologies for flexible deployment and easy system expansion. Integrated AI features including QuickPick 2.0, face detection, face recognition, perimeter protection, SMD Plus, AI video quality analytics, privacy protection, scene changing detection, irregular black block masking, and EPTZ significantly improve event detection accuracy and reduce false alarms. Supporting up to 16 IP camera channels, 4K HDMI output, dual-stream recording, intelligent playback modes, and up to 16TB storage capacity, this recorder provides a powerful and reliable surveillance solution for modern security environments.

Product Highlights

8-Channel AI XVR With QuickPick 2.0 Intelligent Search
Supports HDCVI, AHD, TVI, CVBS & Up To 16 IP Cameras
Face Recognition, Perimeter Protection & SMD Plus AI Analytics
4K HDMI Output With 128 Mbps Network Bandwidth
AI Video Quality Analytics & Scene Change Detection
Supports Up To 16TB Storage With Mobile Monitoring

Technical Specifications

This intelligent AI-enabled XVR combines multi-format camera compatibility, advanced video analytics, face recognition capabilities, intelligent event detection, and flexible IP camera expansion to deliver comprehensive surveillance performance.

Main Processor
: Industrial-Grade Processor
Operating System
: Embedded Linux
Operating Interface
: Web & Local GUI
QuickPick 2.0
: 2 Channels
Face Detection
: 2 Channels (Up To 12 Face Images/S Per Channel)
Face Recognition
: 2 Channels
Face Attributes
: 6 Attributes
Face Database Capacity
: Up To 10 Face Databases With 20,000 Images
Privacy Protection
: 1 Channel
Perimeter Protection
: Advanced Mode 2 Channels, General Mode 8 Channels
SMD Plus By Recorder
: 8 Channels
SMD Plus By Camera
: 16 Channels
AI Video Quality Analytics
: 8 Channels
Scene Changing Detection
: 1 Channel
Irregular Black Block Masking
: 1 Channel
EPTZ
: 1 Channel
Analog Camera Input
: 8 BNC Ports (HDCVI/AHD/TVI/CVBS Auto Detect)
IP Camera Access
: Up To 16 Channels
Default IP Channels
: 8 IP Channels + 8 Converted Analog Channels
Network Bandwidth
: 128 Mbps Incoming / Recording / Outgoing
Dual Stream
: Supported
Video Bit Rate
: 32 kbps – 6144 kbps
Audio Sampling
: 8 kHz, 16-bit
Audio Bit Rate
: 64 kbps
Video Output
: 1 HDMI, 1 VGA
HDMI Resolution
: Up To 3840 × 2160 (4K)
Multi-Screen Display
: 1/4/8/9 (Standard), 1/4/8/9/16 (IP Extension Mode)
Third-Party Camera Support
: Panasonic, Sony, Hanwha, Axis, Arecont & ONVIF
Video Compression
: AI Coding, Smart H.265+, H.265, Smart H.264+, H.264
Audio Compression
: G.711a, G.711u, PCM
Network Protocols
: HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, FTP, DDNS, SNMP, Alarm Server, P2P & Auto Registration
Mobile Access
: iOS & Android
Browser Support
: Chrome, IE, Safari, Edge & Firefox
Record Modes
: General, Alarm, Motion Detection, Intelligent & POS
Playback Channels
: 1 / 4 / 9
Playback Modes
: Instant, General, Event, Tag & Smart Playback
Backup Method
: USB Device & Network
General Alarm
: Motion Detection, Alarm Box, HDCVI Alarm, Camera External Alarm, Network Alarm & PIR Alarm
Anomaly Alarm
: Disk Error, Disk Full, Network Disconnection, IP Conflict, Video Loss, Video Tampering & Camera Offline
Intelligent Alarm
: Face Detection, Face Recognition, Perimeter Protection & SMD Plus
Audio Input
: 1 RCA + 8-Channel BNC Coaxial Audio
Audio Output
: 1 RCA
Two-Way Audio
: Supported
Disk Interface
: 1 SATA Port, Up To 16TB
RS-485
: 1 Port
USB Ports
: 1 Front USB 2.0 + 1 Rear USB 3.0
Network Port
: 1 × 10/100/1000 Mbps RJ-45
Power Supply
: 12 VDC, 2A
Power Consumption
: Less Than 10W (Without HDD)
Net Weight
: 1.20 kg
Gross Weight
: 1.40 kg
Product Dimensions
: 325.0 × 257.1 × 55.0 mm
Packaging Dimensions
: 372.0 × 117.0 × 308.0 mm
Operating Temperature
: –10°C To +55°C
Storage Temperature
: –20°C To +60°C
Operating Humidity
: 10%–90% RH, Non-Condensing
Installation
: Desktop
Certifications
: CE-LVD, CE-EMC & FCC Part 15 Subpart B
